P O R T A L T I +
Portal Installation Manual 6
Document #: PTL1001
1.4.2 Power Requirements
The Portal requires 120 VAC, 8 Amps service. In applications where barrier gates are to be
used, each gate requires 120 VAC, 5 Amps service. The Portal and Gate must be powered
from separate circuits.
Ensure the protective earth ground wires do not carry any motor return current. Only
the neutral wire should carry return current. Follow local electrical code when wiring
the Portal TI+.
1.4.3 Site Wiring Requirements
Wiring requirements will vary by site depending on the type of wash equipment and the Portal
configuration. The following table shows site wiring, which may be needed. As wires are
pulled through conduit, ensure there is at least 6 ft. of wire extending from the end of the
conduit stub.
Portal Power (115-120 VAC, 8 Amps).
16 AWG minimum, black/white/green
Gate Power (115-120 VAC, 5 Amps).
16 AWG minimum, black/white/green
Network connection (to router)
Cat 5 communications cable, 295 ft max length
Wash Signaling (required if the Portal will be
connected to the wash controller)
Refer to wash equipment manufacturer’s
instructions
(required for dial-up credit option)
2 Pair / 4 Conductor Telephone Cable
(Required to interface with site intercom)
(Required for Portal camera option)
Type RG59/U coaxial cable
Gate Control – from gate controller to Portal
(Required if gate controller is used)
Gate Control - from gate controller to gate
(Required if gate controller is used)
Gate Control – from Portal to Gate
(Required if gate is used without gate controller)
(from RFID Antenna to Portal)
Cable is supplied with RFID kit
