Unitech HT630 Reference Guide

Copyright 2008 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
13
4. Hardware Update Wizard
The Hardware Update Wizard will help guide
you through the necessary steps to install the
HT630 USB driver for your PC:
• On the first screen the Hardware
Update Wizard asks to search for
software using Windows Update.
Select “No, not this time”, then click
“Next”.
• The next screen asks “What do you
want the wizard to do?”
Select “Install from a list or specific
location”, then click “Next”.
5. Locate Driver
The next screen prompts you to choose your
search and installation options.
• Select “Search for the best driver in these
locations.”
• Select “Search removable media”, then
click “Next”.
6. Complete Installation
The Hardware Update Wizard will search for
the necessary driver and install it on your PC.
Click “Finish” to complete the installation.
Once the installation for the USB driver is
complete, the Hardware Update Wizard will
open again to create the virtual com port for
your HT630 to communicate with your PC.
Repeat steps 3 - 5 to create the virtual com
port.
Your HT630 is now ready to communicate with
your PC.

Unitech HT630 Specifications

General

Display diagonal	- \
Display resolution	128 x 64 pixels
Display number of colors	Monochrome
ROM capacity	0.256 MB
Internal memory	0.0005 GB
Internal memory type	RAM
Compatible memory cards	Not supported
Maximum internal memory	4.5 MB
Processor family	-
Processor frequency	0.8 GHz
Interface	RS-232
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	120 mAh
Battery life (max)	12 h
Battery recharge time (off)	2.5 h
Certification	BSMI, CCC, CE, FCC, VCCI, RoHS
Product color	Blue
Barcode reader	Yes
Keyboard layout	Alphanumeric
Keypad number of keys	27

Weight and Dimensions

Depth	35.1 mm
Width	67.1 mm
Height	167.64 mm
Weight	243.81 g
