HT630 Product Reference Guide
Cradle
There are two ways to charge the main battery via the HT630 charging/communication cradle or a quick
charging /communication cable.
Cradle LED Icons
The icon indicates communication. When HT630 is transmitting data with the host
computer, LED will flash, showing that the data is transmitting.
The icon indicates the charging of the main unit. When the main battery is in charge on the
cradle, LED will be shown red; when fully charged, the light will turn to green.
This LED light shows the power status of the cradle itself. When the light is on, it is
indicated the cradle is powered on.
Power On
After charging completely, LED is turned to green and then, you are now ready to turn on the unit.
Press ( ☉) on the keypad to turn on the HT630!
Communication with the Host
RS232 Connection through
cable
RS232/Modem/Ethernet Communication
1. 6 Interface Ports
The HT630 does its’ communication via RS232 communication port located in the back of the unit. You
can connect the unit via the communication cable to PC RS232 jack for data transfer or connect through
cradle for communication.

Unitech HT630 Specifications

General

Display diagonal	- \
Display resolution	128 x 64 pixels
Display number of colors	Monochrome
ROM capacity	0.256 MB
Internal memory	0.0005 GB
Internal memory type	RAM
Compatible memory cards	Not supported
Maximum internal memory	4.5 MB
Processor family	-
Processor frequency	0.8 GHz
Interface	RS-232
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	120 mAh
Battery life (max)	12 h
Battery recharge time (off)	2.5 h
Certification	BSMI, CCC, CE, FCC, VCCI, RoHS
Product color	Blue
Barcode reader	Yes
Keyboard layout	Alphanumeric
Keypad number of keys	27

Weight and Dimensions

Depth	35.1 mm
Width	67.1 mm
Height	167.64 mm
Weight	243.81 g
