MS852B Plus User’s Manual
Mechanical
Scanner Dimension 87.8 mm x 177.7 mm x71.6 mm (L x H X W)
Cradle Dimension 120.6 mm x 86.0 mm x 88.7 mm (L x H X W)
Weight 213g (without cradle)
Trigger Switch Life 10 million times
Functionality
Symbologies
1D: Codabar, Code 11, Code 128, Code 2 of 5, Code 39,
Code 93 and 93i, EAN/JAN-13, EAN/JAN 8, IATA Code 2 of
5, Interleaved 2 of 5, Matrix 2 of 5, MSI, GS1 Databar,
UPC-A, UPC E, UPC-A/EAN-13 with Extended Coupon
Code, Coupon GS1 Code 32(PARAF)
2D:
EAN-UCC Emulation, GS1 Data Bar, TLC392D Stacked:
Codablock A, Codablock F, PDF417, MicroPDF4172D
Matrix: Aztec Code, Data Matrix, MaxiCode, QR Code,
Chinese Sensible (Han Xin), Grid Matrix, Dot CodePostal:
Australian Post, British Post, Canadian Post, China Post,
Japanese Post, Korea Post, Netherlands Post, Planet
Code, Postnet
OCR Barcodes: Support OCR barcodes
Electrical
Indicator LED & Beeper & Vibrator
Battery Type Rechargeable and replaceable battery pack
Battery Capacity 2850mAh
Battery Charging time <6.5 hours
Operating Time >25 hours (Based on 1 scan/5 seconds)
Environmental
ESD Protection Functional after 8K Contact and 15K Air
Mechanical Shock 2.1M onto concrete (scanner only)
Operating Temperature -10°C to 50°C (14°F to 122°F)
