Unitech PA500 User Manual

Chapter 4 Wireless Communications
29
Connectivity Features
You can use your device to exchange information with other mobile devices and connect to your
computer, a network, or the Internet. You have the following options:
• Use the infrared sensor or Bluetooth function to exchange files from another IR- or Bluetooth-
enabled device.
• Use Wi-Fi connection to send and receive email messages by using Messaging and view Web
pages by using Internet Explorer Mobile.
Beam Function
In a Microsoft Windows Mobile program (except Messaging) and Picture & Videos, you can exchange
files using either infrared or Bluetooth.
NOTE: You can also beam files (not folders) from the File Explorer screen. To do so, tap and
hold the item you want to send, then tap Beam File from the pop-up menu.
You need to first activate the beam function before you can begin exchanging files with another IR- or
Bluetooth-enabled device.
To activate the Beam function:
1. Tap Start → Settings.
2. On the Connections tab, tap Beam.
3. Tap “Receive all incoming beams” check box.
4. Tap ok.

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
