Unitech PA500 User Manual

Chapter 4 Wireless Communications
33
d. On the Partnership Settings screen, type in a device name and select the type of services
you want to enable for the Bluetooth partnership.
e. Tap Finish.
f. On the Bluetooth screen, tap the COM Ports tab.
g. To connect to a device, tap New Outgoing Port.
h. To allow other devices to connect to your device, tap New Incoming Port.
i. Select the device you want to add, then tap Next.
j. Select a numbered COM port from the list.
k.
Select “Secure Connection” check box to designate the COM port for Bluetooth partnership.
l.
Tap Finish.
m. Tap ok.
To send files via Bluetooth:
1. Locate the item you want to send.
2. Do any one of the following:
– Tap and hold the item, and then tap Beam Task on the pop-up menu.
– Using Pictures & Videos, tap and hold a thumbnail to display a pop-up menu of available
actions, then tap Beam.
– Using File Explorer, tap and hold an item (but not folders), select Beam File on the pop-up
menu.
3. Select the Bluetooth device, then tap Tap to send.
4. Tap ok.
To receive files via Bluetooth:
1. Turn on the Bluetooth function.
2. Send the file from the other bluetooth device.
3. On the Bluetooth callout, tap Yes.
For detailed information on how to use Bluetooth, tap Start → Help.

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
