Unitech PA500 User Manual

Unitech Electronics Co., Ltd Created
by Yukiko
PA500 Operation
Manual
V2.0 Page 119 of 123
D1.5 Devices found. Select the host you want to link. Tap “Next”.
D2. Define Serial port
D2.1. Select Service. Select “Dialup Networking”. Tap “Finish”.
D2.2. Go to “COM Ports” tab, tap “New Outgoing Port”
D2.3. Select the COM port: COM8. Tap OK. (You may select any COM port)
D3. Run VBTerminal tool to connect (VBTerminal can be obtained from
Unitech)
D3.1 Double tap VBterminal tool.
D3.2 Under “Set”, select “setting”.
D3.3 Comport: select 8 (same as D2.3)
D3.4 Buad rate: 115200
D3.5 Tap “Save”.
D3.6 Save set. Tap “OK”.
D3.7 Select “File” > Connect
D4. Search Host’s Bluetooth com port
Refer to chapter 9.1 A1. (ex: Com port = COM5)
D5. Run Hyper Terminal
D5.1 On your host, run Start/Program/HyperTerminal.
D5.2 Define a name for the terminal connection.
D5.3 Connection: select COM5 (Host’s Bluetooth COM port)

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
