Unitronics Vision V130-T2 - Page 14

Vision™PLC+HMI Installation Guide
14
Unitronics
Vision™PLC+HMI
V130-33-T2/V130-J-T2
V350-35-T2/V350-J-T2
V430-J-T2
Technical Specifications
Order Information
Item
V130-33-T2
PLC with Classic panel, Monochrome display 2.4"
V130-J-T2
PLC with Flat panel, Monochrome display 2.4"
V350-35-T2
PLC with Classic panel, Color touch display 3.5’’
V350-J-T2
PLC with Flat panel, Color touch display 3.5’’
V430-J-T2
PLC with Flat panel, Color touch display 4.3’’
You can find additional information, such as wiring diagrams, in the product’s installation guide
located in the Technical Library at www.unitronics.com.
Power Supply
Item
V130-T2
V130J-T2
V350-T2
V350J-T2
V430J-T2
Input voltage
24VDC
Permissible range
20.4VDC to 28.8VDC with less than 10% ripple
Max. current
consumption
See Note 1
npn inputs
210mA@24VDC
230mA@24VDC
230mA@24VDC
pnp inputs
110mA@24VDC
135mA@24VDC
135mA@24VDC
Notes:
1. To calculate the actual power consumption, subtract the current for each unused element from the maximum
current consumption value according to the values below:
Backlight
Ethernet card
V130/J
10mA
35mA
V350/J/V430J
20mA
35mA
Digital Inputs
Number of inputs
12. See note 2
Input type
See note 2
Galvanic isolation
None
Nominal input
voltage
24VDC
Input Voltage
pnp (source)
0-5VDC for Logic ‘0’
17-28.8VDC for Logic ‘1’
npn (sink)
17-28.8VDC for Logic ‘0’
0-5VDC for Logic ‘1’
Input Current
8mA@24VDC
Input impedance
3KΩ
Response Time
10ms typical, when used as normal digital
input
Input Cable length
Normal digital
Input
Up to 100 meters
High Speed Input
Up to 50 meters, shielded, see Frequency table below
