Vision™PLC+HMI
Unitronics
15
High speed inputs
Specifications below apply when wired as HSC/shaft-encoder.
See Note 2
Frequency (max)
See Note 3
Cable length (max.)
HSC
Shaft-encoder
10m
30kHz
20kHz
25m
30kHz
13kHz
50m
25kHz
9kHz
Duty cycle
40-60%
Resolution
32-bit
Notes:
2. V130/V350/V130J/V350J/V430J-T2 models comprise a total of 12 inputs.
12 inputs may be used as digital inputs. They may be wired, in a group, and set to either
npn or pnp via a single jumper.
In addition, according to jumper settings and appropriate wiring:
- Inputs 10 and 11 can function as either digital or analog inputs.
- Inputs 0, 2, and 4 can function as high-speed counters, as part of a shaft-encoder,
or as normal digital inputs.
- Inputs 1, 3, and 5 can function as either counter reset, as part of a shaft-encoder,
or as normal digital inputs.
- If inputs 0, 2, 4 are set as high-speed counters (without reset), inputs 1, 3, 5 can function as normal digital
inputs.
3. pnp/npn maximum frequency is at 24VDC.
Analog Inputs
Number of inputs
2, according to wiring as described above in Note 2
Input type
Multi-range inputs: 0-10V, 0-20mA, 4-20mA
Input range
0-20mA, 4-20mA
0-10VDC
Input impedance
243Ω
>150KΩ
Maximum input rating
25mA, 6V
15V
Galvanic isolation
None
Conversion method
Successive approximation
Resolution (except 4-20mA)
10-bit (1024 units)
Resolution (at 4-20mA)
204 to 1023 (820 units)
Conversion time
One configured input is updated per scan. See Note 4
Precision
0.9%
Status indication
Yes – if an analog input deviates above the permissible range, its value will be
1024.
Notes:
4. For example, if 2 inputs are configured as analog, it takes 2 scans to update all analog values.
