Glossary of Terms
Engraving Field – The horizontal work area (24” x 12” or 610 x 305mm) that is accessible by the laser beam for engrav-
ing and cutting – equal to the maximum “page” size for your laser system. Engraving area may vary based on speeds and
thruput.
Exhaust Port – Round spigot located on the back of the enclosure that allows connection of a fume extraction hose.
Fill – A color, bitmap, fountain or pattern applied to the interior area of a vector graphic.
Focus Carriage – The red or black aluminum housing which houses the Focus Lens and #3 Mirror. The Focus Carriage
moves back and forth along the X-Axis arm when rastering or vectoring.
Focus Lens – An optic (part of the focus lens assembly) located in the Focus Carriage that concentrates the laser beam
into a very small, highly intense spot for cutting and engraving.
Focus Tool – An essential tool supplied with every laser system that acts as a gauge to accurately set the distance
from the Focus Lens to the work piece.
