ULS Reference Guide Book
Place a bubble level (1) across the front (2) and rear cart legs (3). Adjust the caster height using the adjustment 1.
screw (4) until both the rear part and the front part of the cart legs are level with respect to each other. Once
the system is level, secure all casters by tightening the nut (5) up against the cart leg.
Open the top door and remove the rubber band that is securing the arm in place.2.
Remove any remaining packing materials and accessories or any other items that may be located inside the 3.
cabinet or on top of the engraving table.
Laser System Leveling
Manually move the Focus Carriage by hand to the upper left corner.4.
