Page 5
MRF-350 BASE STATION
7. Once you have found a location that is absolutely
clean with everything on, test to see if the range is
adequate and that macro reliability is perfect. Start
with the antenna angle set to 45 degrees and posi-
tioned so that the long side of the antenna is facing the
customer’s favorite seating position.
When testing, set both the remote and the MRF-350 to
the same VALID RF ID#. Keep in mind that zero (0) is not a v
alid RF
ID#. Watch the STATUS LED on MRF-350 - it should light every time
you press a button on the remote. This will tell you that the signal was
received and understood. You can ignore the RF LED on the RFX-250 (it
only indicates that a signal was received, not that it was understood).
8. If the range is inadequate,
you may extend wire to any
area that is not giving good
results and place an addi-
tional RFX-250 in that area.
Up to three RFX-250s can be
connected to one MRF-350.
9. Should you need more than six
IR Outputs, connect as many as
three different MRF-350s to one
RFX-250 in a daisy chain using
the supplied cable.
To preserve addressibility, set
each MRF-350 to a different RF
ID number. Remember “0”
(zero) is not a valid RF ID.
