5.3.4. Control Box Visual Inspection
1. Disconnect the power cable from Control Box.
2. Check for any dirt/dust outside the Control Box.
•
Clean with ESD vacuum cleaner if needed.
NOTICE
Using compressed air to clean inside the Control Box can damage components.
•
Do not use compressed air to clean inside the Control Box.
5.3.5. Freedrive Inspection
1. Unmount attachment or set TCP/Payload/CoG according to tool specifications.
2. To move the robot arm in Freedrive:
•
On a standard Teach Pendant, press and hold the Freedrive button.
•
On a 3PE Teach Pendant, rapidly light-press, then light-press-and-hold the 3PE button.
Standard TP 3PE TP
Hardware Manual 57 UR5e
5.Maintenance and Repair
Copyright © 2009–2022 by UniversalRobotsA/S. All rights reserved.
