Univex SRM80+ - Page 16

TRANSMISSION ASSEMBLY
FIGURE 4
ILLUS. No. PART No. DESCRIPTION QTY.
1064035 Transmission Assembly with shafts (SRM 60) 1
1080500 Transmission Assembly with shafts (SRM 80) 1
1 1065009A Transmission Housing Assembly & Vertical Shaft Assembly (SRM60) 1
1080502A Transmission Housing Assembly & Vertical Shaft Assembly (SRM80) 1
2 Oil Tube 1
3 Set Screw #8-32 x 1/4 cup point 1
1065000 Transmission cover assembly (SRM60) 1
1080022 Transmission cover assembly (SRM80) 1
4 Transmission Cover 1
5 Phillips pan head screw #10-32 x 3/8 8
6 Spring Clip 1
7 Flat Washer #10 2
8 Lock Washer #10 2
9 Phillips pan head screw #10-32 x 3/8 2
10 Plug 1
11 Seal 1
12 Hex Head Cap Screw 1/2-20 x 1 4
13 Lock Washer 1/2 4
14 Flat Washer 1/2 4
15 Dowel Pin 1/2 x 3/8 2
1012439A Magnet Kit 1
16 Magnet Holder 2
17 Magnet 2
18 Drain Plug 1/4 NPT 1
1061111A Internal Gear Kit 1
19 Internal Gear 1
20 Socket Head Cap Screw 1/4-20 x 1/2 8
21 Splash Ring 1
22 Label 1
23 Transmission Wrap (SRM60 only) 1
24 Label 1
Page 3.3
