Univex SRM80+ - Input Assembly

INPUT ASSEMBLY
FIGURE 7
ILLUS. No. PART No. DESCRIPTION QTY.
106503A Input Shaft Assembly 1
1 Retaining Ring, External 5101-118 2
2 Bearing 2
3 Input Gear/Shaft 1
4 Seal 1
5 Retaining Ring Internal N5002-244 2
6 Input Housing 1
7 Lock Washer 5/16 4
8 Hex Head Cap Screw 5/16-18 x 3/4 4
9 Sleeve 1












Page 3.10
