Page 5.3
BOWL LIFT SLIDE & FRAME ASSEMBLY
FIGURE 11
ILLUS. No. PART No. DESCRIPTION QTY.
1065008 Bowl Lift Slide and Frame Assembly 1
1 1080025A Bowl Lift Handle Assembly 1
2 Collar with Set Screw 1
3 Thrust Washer (Bronze) 1
4 1064452A Yoke Assembly 1
5 Hex Head Cap Screw 5/16-18 x 1-1/4 2
6 Lock Washer 5/16 2
7 Flat Washer 5/16 2
1062217A Bowl Lift Gear Set 1
8 Thrust Washer 3
9 Miter Gear with Keway & Set Screw 1
10 Key 1
11 Miter Gear with Roll Pin 1
12 Collar with 2 Set Screws 1
1064457A Lead Screw Assembly 1
13 Lead Screw 1
14 1065004 Slide & Frame Assembly 1
15 Flat Washer 3/8 8
16 Lock Nut 3/8-16 8
17 Lock Washer 1/2 4
18 Hex Head Cap Screw 1/2-20 x 2-3/4 4
