POWER BOWL LIFT SLIDE & FRAME (Figure 12)
POWER BOWL LIFT SLIDE & FRAME REMOVAL:
1. WARING: DISCONNECT THE ELECTRICAL POWER SUPPLY CORD.
2. Remove the mixer top cover (Figure 15 [4]) per section 2, Mechanics Maintenance “REMOVAL
OF TOP COVER” instructions on page 2.6.
3. Remove the rear access panel (Figure 15 [5]).
4. Loosen the four 5/16-18 Kep nuts (Figure 12 [11]) and slide the bracket [16] all the way toward
the front of the mixer housing. Remove the chain [10].
5. Disconnect the bowl lift motor leads from the contactor and ground stud. Remove the four Kep
nuts[11] and washers [12 & 13] remove the power bowl lift motor and bracket [16] from the
mixer housing.
6. Remove the drive belt as described in section 2, Mechanics Maintenance “BELT REPLACE-
MENT” instructions on page 2.2.
7. Remove the bowl support assembly per the instructions on page 4.1.
8. Remove the eight 3/8-16 nuts [18] and washers [13] and pull the slide assembly from the mount-
ing studs and remove it from the mixer housing. Place the slide assembly on a sturdy work-
bench.
CAUTION: The slide assembly is heavy.
9. Drive the roll pin from the clutch assembly [9] and remove the clutch assembly and thrust
washer [8] from the lead screw [4].
10. Push the slide assembly all the way down so the lead screw is free of the slide frame.
11. Loosen the two set screws in the collar [7] on the lead screw and remove the collar and thrust
washer [8].
12. Unscrew the lead screw from the floating nut and remove the lead screw from the slide assembly.
13. Remove the four 3/8-16 hex head screws [3] and lock washers [2] from the motor and remove
the motor from the gearbox.
14. Remove the connection plate on the end of the motor and disconnect the motor power lead.
15. Remove the four 5/16-18 hex head screws [14] and lock washers [15] and remove the bracket
[16] from the gearbox [5].
16. Loosen the two set screws and remove the drive sprocket [6] and key from the gearbox output
shaft.
Page 6.1
