POWER TAKE-OFF ASSEMBLY
FIGURE 6
ILLUS. No. PART No. DESCRIPTION QTY.
1065002 Power Take-Off Assembly (SRM60) 1
1080600 Power Take-Off Assembly (SRM80) 1
1 Cover 1
2 Slotted Flat Head Screw 2
3 Power Take-Off Washer 1
4 8800012 Adapter 1
5 Power Take-Off Housing 1
6 Lock Washer 5/16 3
7 Hex Head Cap Screw 5/16-18 x 1 3
8 Seal 1
9 Bearing 2
10 Retaining Ring, Internal 1
11 Bevel Pinion Gear 1
12 PTO Shaft 1
13 1064428A Helical Gear (SRM60) 1
1080015A Helical Gear (SRM80) 1
14 Retaining Ring External 6
15 Key 1
16 Key 1
17 4400229 Knob Assembly 1
