Univex SRM80+ - 4 Bowl Support Assembly

BOWL SUPPORT ASSEMBLY
FIGURE 10
ILLUS. No. PART No. DESCRIPTION QTY.
1065006 Bowl Support Assembly (SRM60) 1
1080503 Bowl Support Assembly (SRM80) 1
1 1061028 Bowl Support (SRM60) 1
1080028 Bowl Support (SRM80) 1
2 1064454 Bowl Pin(SRM60) 2
1080030A Bowl Pin Kit (SRM80) 1
1064322A Bowl Clamp Assembly (SRM60) 1
1064322A Bowl Clamp Assembly (SRM80) 1
3 Belleville Washer 4
4 Lock Nut 3/8-16 2
5 Bowl Clamp 2
6 Shim Washer 2
7 Hex Head Cap Screw 3/8-16 x 3-1/2 2
1064455A Rear Bowl Clamp Assembly (SRM60) 1
1080029A Rear Bowl Clamp Assembly (SRM80) 1
8 Clamp Block 1
9 Socket Head Cap Screw 1/4-20 2
1064445A Slide Cover Assembly (SRM60) 1
1080037A Slide Cover Assembly (SRM80) 1
10 Slide Cover 1
11 Rubber Strip 2
12 Phillips Pan Head Screw #8-32 x 3/8 2
Page 4.3
