BEATER HEAD ASSEMBLY
FIGURE 5
ILLUS. No. PART No. DESCRIPTION QTY.
1064075 Beater Head Assembly 1
1 Beater Head Housing 1
2 Beater Head Shaft 1
3 1200310 Dowel Pin 1/2 x 2 1
4 Bearing 1
5 Spacer 1
6 Bearing 1
7 Retaining Ring, Internal N5002-281 1
8 Seal 1
9 1061003A Pinion Gear Assembly 1
10 Key 1
11 Retaining Ring, External 5101-137 3
12 Socket Head Set Screw 5/16-18 x 1-3/4 2
1064075A Beater Head Hardware Kit 1
13 Washer 1
14 Hex Head Cap Screw 1/2-20 x 1-1/4 left hand thread 1
