POWER BOWL LIFT SLIDE & FRAME ASSEMBLY
FIGURE 12
ILLUS. No. PART No. DESCRIPTION QTY.
1 1067004A Power Bowl Lift Slide and Frame Assembly 1
2 Lock Washer 3/8 4
3 Hex Head Cap Screw 3/8-16 x 1 4
4 1067025A Power Bowl Lift Lead Screw Assembly 1
5 1067010 Gearbox 1
6 1067014A Drive Sprocket Assembly 1
7 Collar with 2 Set Screws 1
8 Thrust Washer 2
9 1067035A Clutch Sprocket Assembly 1
10 1067018 Chain with Master Link 1
11 Kep Nut 5/16-18 4
12 Flat Washer 5/16 4
13 Flat Washer 3/8 12
14 Hex Head Cap Screw 5/16-18 x 3/4 4
15 Lock Washer 5/16 4
16 1067034 Gearbox Mounting Bracket 1
17 1067011 Motor, 1/4 HP, 115/208-230V, 60HZ, 1PH 1
1067012 Motor, 1/4 HP, 208-230V, 60HZ, 3PH 1
18 Lock Nut 3/8-16 8
19 1067026A Power Bowl Lift Up Limit Switch Assembly 1
20 Floating Nut 1
21 1067027A Power Bowl Lift Down Limit Switch Assembly 1
7100012 Contactor 208-240V,60HZ,1/3PH (not shown) 2
7100014 Contactor 460V, 60HZ, 3PH (not shown) 2
7100130 Mechanical Interlock (not shown) 1
1067016 Power Bowl Lift Up/Down Selector Switch (not shown) 1
