SPEED CONTROLASSEMBLY
FIGURE 13
ILLUS. No. PART No. DESCRIPTION QTY.
1065005 Speed Control Assembly (SRM60) 1
1080506 Speed Control Assembly (SRM80) 1
1 1064435A Speed Control Lever Assembly 1
2 Roll Pin 1/4 x 3 1
3 Strap 1
4 Flat Washer 3/8 8
5 Flat Washer 5/16 8
6 Kep Nut 5/16-18 10
7 Socket Head Set Screw 5/16-24 x 1-1/8 2
8 Key 1
9 Speed Control Shaft 1
10 1064439 Speed Control Spring 1
11 1064508A Speed Control Bearing Assembly 1
12 Hex Head Cap Screw 5/16-18 x 3/4 1
13 Hex Head Cap Screw 5/16-18 x 2 (fully threaded) 1
14 Speed Control Bearing Bracket 1
15 1064438A Speed Control Cam Assembly 1
16 Retaining Ring, External 5101-100 2
17 Socket Head Set Screw 5/16-24 x 1-1/8 2
18 Socket Head Set Screw 5/16-24 x 3/8 1
19 Roll Pin 14 x 1-1/2 1
20 1064437A Speed Control Block Assembly 1
21 Spring 1
22 Ball, Steel 1/4 Dia. 1
23 Belleville Washer 1
24 1064436 Detent Housing 1
Page 7.5
