Upright SL-26 User Manual

8
COMPONENT INSPECTION OR SERVICES INTERVAL MODEL Y N R
Elevating Inspect for structural cracks Daily A
Assembly Check pivot points for wear 30D A
Check mounting pin pivot bolts 30D A
for proper torque
Check linkage gear for wear 6M A
Check elevating arms for bending 6M A
Grease linkage pins 30D A
Grease linkage gear 30D A
Chassis Check hoses for pinch or Daily A
rubbing points
Check component mounting 6M A
for proper torque
Check welds for cracks Daily A
Lift Check the cylinder rod for wear 30D A
Cylinder Check mounting pin pivot bolts 30D A
for proper torque
Check pivot pin snap rings 30D A
Check seals for leaks 30D A
Inspect pivot points for wear 30D A
Check fittings for proper torque 30D A
Entire Check for and repair Daily A
Unit collision damage
Check fasteners for proper torque 3M A
Check for corrosion-remove 6M A
and repaint
Lubricate 30D A
Labels Check for peeling, missing, or Daily A
unreadable labels & replace
Wheel Check wheel assembly for play 30D A
Bearings Repack wheel bearings 2Y A
(replace wheel bearings and
seals at 2000 hrs.)
Service Report
Date: ______________
Owner: _______________________________
Model No: ___________ Serial No: ________
Serviced By: ___________________________
Service Interval: ________________________
Routine Service Table Key
Interval
Daily=each shift (every day) or every eight hours
30
D=every month (30 days) or every 50 hours
3
M=every 3 months or 125 hours
6
M=every 6 months or 250 hours
1
Y=every year or 500 hours
2
Y=every year or 1000 hours
Model
A= All Models
E= Electric Models
D= Dual Fuel Models
Y=Yes/Acceptable
N=No/Not Acceptable
R=Repaired/Acceptable
Routine Service
Use the following table as a guide for routine
maintenance. Inspection and maintenance shall
be performed by personnel who are trained
and familiar with mechanical and electrical
procedures. Refer to the Service Manual for
complete service instructions.
Please copy the following page and use the
Routine Service table as a checklist when inspect-
ing a machine for service.
COMPONENT INSPECTION OR SERVICES INTERVAL MODEL Y N R
Battery Check electrolyte level Daily A
System Check specific gravity 30D A
Clean exterior 6M A
Check battery cable condition Daily A
Charge batteries Daily E
Clean terminals 6M A
Engine Oil Check level and condition Daily D
Check for leaks Daily D
Change oil filter 30D D
Engine Fuel Check fuel level Daily D
System Check for leaks Daily D
Replace fuel filter 6M D
Check air cleaner Daily D
Hydraulic Oil Check oil level Daily A
Change filter 6M A
Drain and replace oil 2Y A
Hydraulic Check for leaks Daily A
System Check hose connections 30D A
Check hoses for exterior wear 30D A
Emergency Open the emergency lowering Daily A
Hydraulic valve and check for
System serviceability
Controller Check switch operation Daily A
Control Check the exterior of the cable Daily A
Cable for pinching, binding or wear
Platform Check fasteners for proper torque Daily A
Deck and Check welds for cracks Daily A
Rails Check condition of deck Daily A
Tires Check for damage Daily A
Check air pressure (50 psi-B78 x 13 ST) Daily A
Check lug nuts (torque to 90 ft. lbs. [123 Nm]) 30D A
Hydraulic Wipe clean 30D A
Pump Check for leaks at mating surfaces 30D A
Check for hose fitting leaks Daily A
Check mounting bolts for proper torque 30D A
Check the drive coupling for proper
torque and alignment 1Y A
Lubricate pump splines (Kohler Only) 6M D
Drive Motors Check for operation and leaks Daily A
Steering Check hardware & fittings 6M A
System for proper torque
Grease pivot pins 30D A
Oil king pins 30D A
Check steering cylinder for leaks & 30D A
mounting bolts for proper torque
