Tyres / Check tyre press. 65 psi (4.5 bar) Daily
Wheels Check for damage. Daily
Check thread depth. Daily
Check/torque nuts 74 ft lbs-100 Nm Daily
Platform Check welds for cracks. Daily
Deck and Check condition of floor. Daily
Guardrails Check that securing bolts are Daily
tightened.
Check drop bar on cage entrance. Daily
Slew Grease slew gear. 50h/30d
System Check slew motor for leaks and 50h/30d
mounting bolts for proper torque.
Slew Check torque on all bolts, 15 outer 50h/30d
System/ ring and 20 inner ring.
First Post Retorque to 88 ft lbs (120 Nm).
Elevating Inspect for structural cracks. Daily
Assembly Check hoses for pinch or rubbing Daily
points.
Check pivot pins for damage. 50h/30d
Check pivot pin retaining rings. 50h/30d
Lift Check cylinder rod for wear. 50h/30d
Cylinders Check pivot pin retaining rings. 50h/30d
Grease all fittings as section 4.4. 50h/30d
Chassis Inspect for structural cracks. Daily
Assembly Check hoses for pinch or rubbing Daily
points.
Entire Unit Function check Emergency stop Daily
switches at control boxes.
Perform pre-operation inspection. Daily
Check for/repair collision damage. Daily
Lubricate. 50h/30d
Grease all fittings. 50h/30d
Outriggers Check outrigger cylinders for Daily
damage.
Check interlock switch function. Daily
Lubricate. 50h/30d
Grease all fittings. 50h/30d
Tow Hitch Check coupling for function and Daily
wear.
Inspect breakaway cable for Daily
proper attachment.
Grease all fittings as per the 50h/30d
Service & Parts Manual Section 4.4
Road Check all trailer lights and Daily
Lights connecting plug
Brake Apply handbrake and check Daily
function.
Check brake shoes for wear. 50h/30d
Test auto reverse function. 50h/30d
Adjust brake shoes. 50h/30d
ROUTINE SERVICE
Use the following table as a guide for routine maintenance.
Inspection and maintenance shall be performed by
personnel who are trained and familiar with
mechanical and electrical procedures. Refer to the
Service & Parts Manual for complete service instructions.
Interval
Daily = each shift or every day
50h/30d = every 50 hours or 30 days
Y=Yes/Acceptable
N=No/Not Acceptable
R=Repaired/Acceptable
Preventative Maintenance Report
Signature of Service Engineer
_____________________________
Date :________________________________
Owner : ______________________________
Model No : ____________________________
Serial No :____________________________
Serviced By :__________________________
Service Interval :________________________
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
Battery Check electrolyte level Daily
System Check battery cable condition. Daily
Charge batteries. Daily
Check specific gravity. 50h/30d
Hydraul. Oil Check oil level. Daily
Hydraulic Wipe clean. 50h/30d
Pump Check for hose fitting leaks 50h/30d
Check for leaks at mating surfaces. 50h/30d
Check mounting bolts for proper 50h/30d
torque.
Hydraulic Check for leaks. Daily
System Check hose connections. 50h/30d
Check for exterior wear. 50h/30d
Emer. Open the emergency lowering Daily
Hydraulic valves and check for proper
System operation.
Control Check switch operation. Daily
Cable Check the exterior of cable for Daily
pinching, binding or cable wear.
