UPRtek PG200N - PPFD Mode

19
3.3 PPFD Mode
Click “PPFD” icon in main menu to validate Photosynthec
Photon Flux Density (PPFD). Measuring range is 350~800nm. In
addion, items and ranges to measure can also be customized;
instrucons are shown in the figure.
Customize the four measurement
items in PPFD mode.
Click the item to be changed.
1
Changeablemeasurementitem
2
Click items to be shown in
posion ①. Click “ ” key at
boom of screen to back to last
page without selecng any item.
Default item changed. Follow
the same steps to change
other default items.
3
20
3.3 PPFD Mode
Customizing measurement range
1. Press the “PFD-custom” item.
2. Select the start and end values in order to change the range.
3. Use the keyboard to input the values; press “OK” when completed.
4. Press the confirm buon “

” to complete the sengs for
changing the range.
5. Return to the measurement page and the yellow value under
“PFD-custom” is updated based on the customized range.
1 3
4
2
5
