05
2.1 Preparing Before Use
1.
2.
3.
4.
Charge the baery for 6 hours before using it for the first me.
To prevent power outage during use, check whether the red light
has turned off (fully charged) according to the instrucons given on
the next page (Item1). Once the spectrometer is turned on, keep
an eye on the baery charge indicator at the upper right corner of
screen.
If your baery drains quickly aer being fully charged, it needs to
be replaced. Please contact your dealer.
Baery life varies with baery age and usage. A new baery
typically lasts about 5 hours aer a full charge.
2. A flash symbol displays at upper
right corner of the LCD screen
during charging and disappears
aer it is fully charged.
Charging method
Connect the charger and USB cable to the Type C USB port of
this product to start charging.
1. While powered OFF, the red indicator will light up during
baery charging; the red indicator will go off once the
spectrometer is fully charged.
06
2.1 Preparing Before Use
Open the dustproof cover and insert the MicroSD card in the
specified direcon.
Press to remove MicroSD card
1 2
Installing MicroSD card
Measurement data may be saved in Excel (xls) format and image
data (spectrum and chromacity coordinates diagram) may be
saved in JPG format in the MicroSD card with capacity at 1GB or
more.
1. The SD card features a card latch design to prevent it from coming
loose. You may feel that the SD card is stuck when it is inserted in
or removed. In this case, pull or push it a lile harder to get it in
place or removed. To remove SD card: Press it as shown in step ①
and pull it out aer ejecng as shown in step ②.
To Next Page
