LPX SEED TREATER
DRUM & ATOMIZER 3HP MOTOR KIT (03-20-0101)
Item # Part #
Description Qty
1 01-01-0105
MTR .33HP 1725RPM 56C 3PH TENV 1
2 01-01-0166 MTR 3HP 1740RPM 182TC TEFC 3PH 1
3 05-10-0805 DISK ATOMIZER MOTOR 1
4 06-01-0016 BOLT .375-16 X 1.00 ZP GR5 8
5 06-04-0003 WSHR LOCK SPLT .375 ZP 8
