Page 20
LPX SEED TREATER
LPX MANUAL TREATER SET - UP
10. Connect any conveyors
that need to be controlled
through the touch screen
to the bottom of the treater
control panel.
11. Connect the communication
cable from the pump stand(s)
to any of the four two-wire
connectors on the bottom
of the main treater panel.
12. Ensure the two included red
plugs are inserted into the
PJESTOPA and PJESTOPB
connectors.
12
10
11
To Next Page
