USFilter V-2000 - Location of Components

IM 25.055AC UA (C/6-01)
AUTOMATIC CHLORINATOR - 3000LB/24HR
6
WARNING: THIS CONTROL MODULE IS DESIGNED TO OP-
ERATE UNDER VACUUM ONLY. TO AVOID POSSIBLE SE-
VERE PERSONAL INJURY OR EQUIPMENT DAMAGE, DO NOT
CONNECT TO A SOURCE OF GAS UNDER PRESSURE.
2.1 Location of Components
The general physical requirements of the installation are shown on the
Typical Installation drawings. Locate the control module so that the nec-
essary gas and power supplies may be connected. Ready access to the
equipment for operation, routine maintenance, and service is required.
Locate the injector so that the water supply, solution line to the point of
application, and suction lines are connected with access for service con-
veniently provided.
2.2 Gas Supply
For gas supply installation details, refer to the separate instruction book
provided with the vacuum regulator (which regulates the gas supply to the
control module).
2.3 Unpacking
When the equipment and accessory items are unpacked, check all items
against the packing list to be sure that no parts are discarded with the
packing material. Whenever possible, unpack the equipment at the instal-
lation site. Set aside items not required at the time of installation, such as
spare parts, where they will be available when needed.
WARNING: TO AVOID POSSIBLE SEVERE PERSONAL INJURY
OR EQUIPMENT DAMAGE, DO NOT DISCARD OR REMOVE
THIS INSTRUCTION BOOK WHEN THE INSTALLATION IS
COMPLETED. THE OPERATOR WILL NEED IT.
CAUTION: To prevent damage to the module, replace the shim
washers underneath the module after the plywood feet are removed.
2.4 Pressure Relief Valve
WARNING: TO AVOID POSSIBLE SEVERE PERSONAL INJURY
OR EQUIPMENT DAMAGE, A PRESSURE RELIEF VALVE
MUST BE INSTALLED THE SYSTEM.
NOTE: See appropriate Typical Installation drawings.
!
!
!
!
