IM 25.055AC UA (C/6-01)
AUTOMATIC CHLORINATOR - 3000LB/24HR
61
SECTION 5 - ILLUSTRATIONS
List Of Contents
DRAWING NO.
Parts
Basic Components .............................................25.055.000.052A-D
Chlorine Rotameter............................................25.056.005.010A&B
V-Notch Plug Components................................25.056.004.010
Vacuum Differential Regulating Valve .............. 25.056.003.010A&B
2" Injector - With Pressure-Operated Plug
Shut-Off ..........................................................25.052.001.046A&B
2" Injector - With Manually Operated Plug
Shut-Off ..........................................................25.052.001.051A&B
U19315 Injector Shut-Off Unit..........................25.100.06.111
AAA4316 1" Standard Injector .........................25.200.002.030A&B
Junction Box ......................................................25.055.000.017A&B
AAA4313 1" Anti-Syphon Injector ...................25.200.002.040A&B
Plastic 1" Fixed Throat Injector and Tailway
Details .............................................................25.200.003.010A&B
AAA4310 3/4" Standard Injector ......................25.200.002.010A&B
AAA4307 3/4" Anti-Syphon Injector ................25.200.002.020A&B
Main Connections - For Hose ............................50.845.02.011
Plastic Main Connection - For 3/4" or 1"
Solution Lines With 1" Corporation Cock......50.845.06.011
Main Connection - For 1-1/2" Solution Line .....50.845.006.021
Main Connection - For 2" and 3" Rigid Plastic
Pipe .................................................................50.845.006.031
Module Enclosure ..............................................25.055.004.010A&B
GAA1046 Dual or High and Low Vacuum
Switch Connections ........................................55.116.020.015A&B
Connections For Gas Flow Transmitter
AAA7427 3000lb Series V2000 Gas Feeder ..55.114.010.020A-C
