IM 25.055AC UA (C/6-01)
AUTOMATIC CHLORINATOR - 3000LB/24HR
INTRODUCTION
This instruction book provides installation, operation, and maintenance
instructions for the USFilter's Wallace & Tiernan Products (USF/W&T)
Series V-2000 (Chlorine) Gas Feeder (control module and injector). Of
necessity, more information is provided than applies to each specific instal-
lation; disregard those details that do not apply to your installation.
Instructions for accessory equipment, where applicable, are provided in
separate books included with that equipment.
The complete gas feeder consists of a control module, an injector, and a
vacuum regulator. The vacuum regulator is covered by a separate instruc-
tion book provided with that equipment.
WARNING: DO NOT USE THIS EQUIPMENT FOR SWIMMING
POOL, WATER PARK, OR SIMILAR RECREATIONAL APPLI-
CATIONS. IT IS NOT SOLD FOR SUCH USE.
The USF/W&T Gas Feeder is designed to meter and control the flow of
chlorine gas. An injector accepts this flow of gas, mixes it with water, and
delivers the resultant solution to the point of application. By using a selec-
tion of rotameters and valve seats, the gas feeder may be adapted to meet
a wide range of capacity requirements. Thus, as requirements change over
a period of time, the capacity of the gas feeder may be changed accordingly.
A large indicator scale on the rotameter permits a direct reading of the rate
of gas feed in pounds per 24 hours. Control of the feed rate is electric;
however, a simple release mechanism permits the operator to assume
manual control at any time. The gas feeder is normally equipped with a
two-inch variable throat injector.
WARNING: HAZARDOUS GAS IS PRESENT IN THIS EQUIP-
MENT DURING NORMAL OPERATION. TO AVOID POSSIBLE
SEVERE PERSONAL INJURY OR DAMAGE TO THE EQUIP-
MENT, READ THIS INSTRUCTION BOOK AND THE APPRO-
PRIATE GAS MANUAL BEFORE CONNECTING THIS EQUIP-
MENT TO A SUPPLY OF GAS. OPERATION AND MAINTE-
NANCE OF THIS EQUIPMENT MUST BE RESTRICTED TO
TRAINED, QUALIFIED PERSONNEL WHO ARE COMPLETELY
FAMILIAR WITH THESE INSTRUCTIONS. CONSULT FAC-
TORY FOR APPLICATIONS AGAINST A NEGATIVE HEAD
(PARTIAL VACUUM) OR A POSITIVE BACKPRESSURE OF
LESS THAN 1.0 PSI (28 INCHES OF WATER) IN THE SOLUTION
DISCHARGE LINE.
!
!
