IM 25.055AC UA (C/6-01)
AUTOMATIC CHLORINATOR - 3000LB/24HR
45
ACID, OBSERVE ALL SAFETY PRECAUTIONS RECOM-
MENDED BY THE ACID MANUFACTURER/SUPPLIER.
f. Wipe a thin film of Halocarbon grease on the O-ring (5) before
installing it on the stem.
g. Look through the opening in the top of the injector with a flash-
light and examine the conical hole and O-ring in diaphragm screw
immediately below. If it is smooth and clean, merely reinstall the
stem, making sure the large O-ring is under the head. If the coni-
cal hole and O-ring show film deposits, clinging particles, or a
rough surface, disassemble the injector. Unscrew the gas line union
nut (15) and discard O-ring (16).
h. Remove six bolts and lift off injector flange. Carefully remove the
diaphragm assembly. Using a fine, pointed tool, pierce the O-ring
(8) and remove it from the valve seat (7). Clean the conical hole
in the diaphragm screw. Do not scrape with a knife blade or a
tapered reamer. Scrub out with a cloth plug. Dissolve resistant
deposit with 10% muriatic (hydrochloric) acid. It is not necessary
to disassemble the diaphragm to do this.
WARNING: TO AVOID POSSIBLE SEVERE PERSONAL INJURY
OR EQUIPMENT DAMAGE WHEN USING HYDROCHLORIC
ACID, OBSERVE ALL SAFETY PRECAUTIONS RECOM-
MENDED BY THE ACID MANUFACTURER/SUPPLIER.
i. Reassemble the valve stem (11) to the upper body (13) and re-
place the valve seat O-ring (8) and diaphragm clamping O-ring
(outer).
j. Bolt the flange in place with six bolts.
• Cleaning Poppet Check
a. Unscrew adapter (34) and remove O-ring (35). Discard the O-
ring.
b. Remove poppet (21) and remove O-ring (23). Discard the O-
ring.
c. Clean threads and O-ring grooves by soaking in warm water. Wipe
a thin film of Halocarbon grease on the O-rings and threads.
!
