USTM WS-12-1650-PRIMO - Two-Piece Softener Installation and Assembly; Two-Piece Softener Component Identification

5. Two-piece soener
1. A pressure vessel 10x54
2. Bypass along with accessories:
a. Power supply
b. 1” Connections
c. Fasteners (for connecting the bypass with the head)
d. Allen key
3. The distribution pipe with a lower basket (placed inside the vessel)
4. BNT165 head with the upper basket
5. 3/8" brine line (for connecting the brine tank to the control head injector)
6. Overflow line (outflow to the sewage system)
7. The complete brine tank with a float and overflow spigot
8. Bedding material
9. Ion-exchange resin
10. Salt (optional)
- The head operating instructions
- The device operating instructions
ATTENTION! The 10x54 vessels are not prefilled with the ion-exchange material, they must be
filled by the user according to the recipe.
ATTENTION! Close the water supply valve and drain the line.
1.
3. 4. 5.
6. 7. 8.
podsypka
złoże
9.
a.
c.
d.
b.
5a. Two-piece soener components
18
EN
