8-25
Setup and Registration (System Menu) > System Menu
Printer
Printing from computers, settings are generally made on the application software screen. However, the following
settings are available for configuring the defaults to customize the machine.
Printer
Item Description
Emulation Select the emulation for operating this machine by commands oriented to other types of
printers.
Value: Line Printer, IBM Proprinter, EPSON LQ-850, PCL6, KPDL, KPDL (Auto)
NOTE
When you have selected [KPDL (Auto)], set "Alt Emulation", too.
When you have selected [KPDL] or [KPDL (Auto)], set "KPDL Error Report", too.
Alt Emulation When you have selected [KPDL (Auto)] as emulation mode, you can switch between KPDL and
another emulation mode (alternative emulation) automatically according to the data to print.
Value: Line Printer, IBM Proprinter, EPSON LQ-850, PCL6
KPDL Error Report When an error has occurred during printing in KPDL emulation mode, set whether or not the
error report is output.
Value: Off, On
EcoPrint EcoPrint conserves toner when printing. This is recommended for test copies where faded
printing is not a problem.
Value: Off, On
Override A4/Letter Select whether to treat A4 size and Letter, which are similar in size, as the same size when
printing.
Value
Off: A4 and Letter are not regarded as the same in size.
On: A4 and Letter are regarded as the same in size. The machine will use whichever size
is in the paper source.
Duplex Select binding orientation for duplex mode.
Value: 1-sided, 2-sided Bind LongEdge, 2-sided Bind ShortEdge
Paper Output Select either the inner tray or the optional Rear Tray for the output stack.
Value: Inner Tray Face Down, Rear Tray Face Up
NOTE
This function can be used for P-5035i MFP and P-6035i MFP.
Copies Set the default number of copies, from 1 to 999.
Value: 1 to 999 copies
Orientation Set the default orientation, [Portrait] or [Landscape].
Value: Portrait, Landscape
Wide A4 Turn this to on to increase the maximum number of characters that can be printed in a line for
an A4 page (78 characters at 10 pitch) and Letter size page (80 characters at 10 pitch). This
setting is only effective in PCL 6 emulation.
Value: Off, On
Form Feed TimeOut Receiving print data from the computer, the machine may sometimes wait if there is no
information signaling that the last page does not have any more data to be printed. When the
preset timeout passes, the machine automatically prints paper. The options are between 5 and
495 seconds.
Value: 5 to 495 seconds (in 5 second increments)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Utax P-4030i MFP and is the answer not in the manual?

Utax P-4030i MFP Specifications

General IconGeneral
Duplex printingYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Time to first page (black, normal)9 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Duplex print speed (black, normal quality, A4/US Letter)20 ppm
Copier resize25 - 400 %
Maximum number of copies999 copies
Copy speed (black, normal quality, A4)40 cpm
Scan toE-mail, FTP, SMB, USB
Scan driversTWAIN, WIA
Maximum scan areaA4 (210 x 297) mm
Scan speed (color)30 ppm
Image formats supportedJPG, TIF
Duplex scan speed (black)17 ppm
Duplex scan speed (color)13 ppm
Document formats supportedPDF, XPS
FaxingNo
Digital sender-
Printing colorsBlack
Maximum duty cycle- pages per month
Page description languagesEpson LQ, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3
Cabling technology10/100/1000Base-T(X)
Authentication methodSMTP
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocols (IPv4)TCP/IP
Internal memory1024 MB
Processor model465S
Processor familyPowerPC
Processor frequency667 MHz
Paper input typeCassette
Total input capacity500 sheets
Total output capacity250 sheets
Multi-Purpose tray input capacity100 sheets
Duplex media weight60 - 120 g/m²
Paper tray media typesPlain paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Product colorBlack, Grey
Market positioningBusiness
Standard interfacesEthernet, USB
AC input voltage220 - 240 V
AC input frequency50 Hz
Power consumption (off)2.4 W
Power consumption (standby)60.6 W
Power consumption (average operating)684 W
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012 R2
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Weight and Dimensions IconWeight and Dimensions
Depth455 mm
Width475 mm
Height575 mm
Weight22000 g
