9-11
User Authentication and Accounting (User Login, Job Accounting) > Setting User Login Administration
To change the user information of logged in user (User Property)
These users can partially change their own user properties including user name, login password, E-mail address, and
Simple Login.
Although "Login User Name", "Access Level", or "Account Name" cannot be changed, the users can check the present
status.
1
Display the screen.
1 Press the [System Menu/Counter] key.
2 Press [ ] and then [User Property].
2
Change the user properties.
1 Refer to step 3 of Adding a User (Local User List) to change a user property.
Item Description
User Name Changes the name shown on the user list. Up to 32 characters can be
entered.
Login User Name Displays the login user name that is entered at login.
Login Password Changes the password that is entered at login. Up to 64 characters
can be entered.
Access Level Displays the user's access level.
Account Name Displays the account where the user belongs.
E-mail Address Changes the user's e-mail address. Up to 128 characters can be
entered.
If you log in as a user and [New Destination Entry] is set to [Prohibit],
you can only check the e-mail address.
ID Card Information Displays the ID card information of the logged in user.
NOTE
This function is displayed when the optional ID Card Authentication
Kit is activated.
Card Authentication Kit(B) "Card Authentication Kit" (page 11-3)
This function does not appear when the server type is set to [Ext.] in
Network Authentication, and logged in with the user account
certificated in the server specified as the [Ext.] server type.
User:User A
User A
10:10System Menu/Counter.
Login User Name
Login Password
User Name
User A
Cancel
1/2
Save
**********
Account Name
Others
