UTIFORM HD 50/07 - Page 118

Soladora HD 50/07
NOTA: La empresa Utiform se reserva el derecho de efectuar cualquier modificación técnica con tendencia a mejorar la máquina, aunque no esté contemplada en esta manual.
www.utiform.com departamento.técnico@utiform.com
Tfno. +34 96 570 29 82 Fax: +34 96 678 22 99
16 SISTEMA DE ENGRASE GREASING SYSTEM ZENTRALSCHMIERANLAGE SYSTÈME DE GRAISSAGE
Nº Ref. Uds. Descripción Description Bezeichnung Désignation
1 982750091 2.55 MANG. ENGRASE ALTA PRESION CON GRASA
HOSE FOR GREASING SYSTEM HIGHT
PRESSURE
FETTSCHLAUCH
TUYAU GRAISSAGE HAUTE PRESSION
AVEC GRAISSE
2 853540010 4 CASQUILLO ROSCADO P/EMPALME ENGRASE SOCKET THREADED FOR GREASING ÜBERWURFMUTTER
BAGUE ROSCADO POUR ASSEMBLAGE
GRAISSAGE
3 853380003 3 EMPALME CURVO 90º TUBO ENGRASE BUTT JOINT 90º CURVE GREASING TUBE ROHRSTUTZEN 90º
EMBRANCHEMENT COURBE 90º TUBE
GRAISSAGE
4 040072 2
RACOR RECTO RED. S/JUNTA GAS 1/4"-TN92-
6LR
STRAIGHT CONNECTOR GAS JOINT1/4"-
TN92-6RL
VERBINDUNGSSTÜCK GERADE RED.
M/KUPPLUNG GAS 1/4 TN92-6LR
RACCORD REDUIT SUR JOINT GASOIL 1/4"
- XTN92-6LR
5 41740 2 ARANDELA D7603-A - ENGRASE WASHER DIN7603-A - GREASING KUPFERRING DIN7603-A RONDELLE DIN7603-A - GRAISSAGE
6 406400 1 ELEMENTO BOMBA KFG1.U1 PUMP ELEMENT KFG1.U1 PUMPENELEMENT KFG1.U1 ELEMENT POMPE KFG1.U1
7 41211 5 TUERCA AUTOBLOC. D985 M8 SCREW AUTOBLOC. D985 M8 MUTTER SELBSTHEMMEND DIN 985 M8 ECROU AUTOBLOQUANT D985 M8
8 41702 3 ARANDELA D125A M8 WASHER D-125A M8 U-SCHEIBE D125 M8 RONDELLE D-125A M8
9 41111 3 TORNILLO D933 M8x25 SCREW D933 M8x25 SCHRAUBE D933 M8X25 VIS D933 M8x25
10 5900000009 1 KIT SISTEMA ENGRASE CONVEY 260 GREASE TANK 2 KG SCHMIERFETTBEHÄLTER 2 KG RESERVOIR GRAISSAGE 2KG.
5900000005 1 DEPOSITO ENGRASE 2 KG. GREASE TANK 2 KG SCHMIERFETTBEHÄLTER 2KG RESERVOIR GRAISSAGE 2KG.
11 406401 1 ELEMENTO BOMBA KFG1.U4 PUMP ELEMENT KFG1.U4 PUMPENELEMENT KFG1.U4 ELEMENT POMPE KFG1.U4
12 1800411011 1 TUBO PROTEC. MANG. ENGRASE CALDERA
PROTECTION TUBE GREASING HOSE
VESSEL
SCHUTZROHR
TUBE PROTECTION TUYAU GRAISSAGE
CUVE
13 41202 2 TUERCA D934 M8 SCREW D934 M8 MUTTER D934 M8 ECROU D934 M8
14 853380002 1 EMPALME RECTO TUBO ENGRASE BUTT JOINT STRAIGHT GREASING TUBE ROHRSTUTZEN
EMBRANCHEMENT DROIT TUBE
GRAISSAGE
15 5900000006 1 KIT SISTEMA ENGRASE CONVEY 260
