UTIFORM HD 50/07 - Page 132

Soladora HD 50/07
NOTA: La empresa Utiform se reserva el derecho de efectuar cualquier modificación técnica con tendencia a mejorar la máquina, aunque no esté contemplada en esta manual.
www.utiform.com departamento.técnico@utiform.com
Tfno. +34 96 570 29 82 Fax: +34 96 678 22 99
Nº Ref. Ud. Descripción Description Bezeichnung Désignation
38314 1
MANG. TRANSP. 65 mm.(20 MTS) C/ACOPL.
P/TRIPODE
MATERIAL HOSE 65 mm.(20 MTS) WITH
COUPLING FOR TRIPOD
TRANSPORTSCHLAUCH MIT
DOPPELTKUPPLUNG FUER
AUSLAUFTOPF 65mm (20M)
TUYAU TRANSP. 65mm (20MTS)
A/RACCORD P/TREPIED
1 41062 28 TORNILLO R/CH. D7981 M4.8x16 SCREW R/CH DIN7981 M4, 8X16 SCHRAUBE R/CH DIN7981 M4, 8X16 ECROU R/CH. DIN7981 M4, 8X16
1.1 41164 4 TORNILLO D603 CARROCERO M5x20 SCREW M5x20 VIS CARROSSIER M5x20
1.2 41216 4 TUERCA AUTOBLOC. D985 M5 SELF BLOCKING SCREW D985 M5 SELBSTKLEMMENDE MUTTER D985 M5 ECROU AUTOBLOQUANT D985 M5
1.3 41708 4 ARANDELA D125A M5 WASHER D-125A M5 UNTERLEGSCHEIBE D125A M5 RONDELLE D-125A M5
2 38310 20 MANG. TRANSP. 65x85 mm. 10 BAR. MATERIAL HOSE 65x85 mm. 10 BAR. MATERIALSCHLAUCH 65x85 mm. 10 BAR. TUYAU TRANSP. 65x85 mm. 10 BAR.
3 85486261 1 ACOPL. NW.65 TRIPODE CUPPLING NW.65 TRIPODE BRINKMANN
KUPPLUNG NW.65 AUSLAUFTOPF
BRINKMANN
RACCORD NW.65 TREPIED BRINKMANN
4 76300 1 ACOPL. HEMBRA KKMT 89 Dn 65 CUPPLING FEMALE KKMT 89 Dn 65 KUPPLUNG WEIBLICH KKMT 89 Dn 65 RACCORD FEMELLE KKMT 89 Dn 65
5 76303 1 JUNTA ACOPL. 65 mm. 110x14 mm. JOINT CUPPLING 65 mm. 110x14 mm. GUMMIDICHTUNG 65 MM 110X14 mm JOINT RACCORD 65 mm. 110x14 mm.
38312 1 MANG. TRANSP. 65 mm.(20 MTS) C/ACOPL.
MATERIAL HOSE 65 mm.(20 MTS) WITH
COUPLING
MATERIALSCHLAUCH 65 MM (20 M) MIT
KUPPLUNG
TUYAU TRANSP. 65 mm. (20 MTS)
A/RACCORD
38314 1 MANG.TRANSP.65 mm (40 MTS) C/ACOPL.
MATERIAL HOSE 65 mm.(40 MTS) WITH
COUPLING
MATERIALSCHLAUCH 65 MM (40 M) MIT
KUPPLUNG
TUYAU TRANSP. 65 mm.(40 MTS)
A/RACCORD
6 76301 1 ACOPL. MACHO KKVT 89 Dn 65 CUPPLING MALE KKVT 89 Dn 65 KUPPLUNG MŽNNLICH KKVT 89 Dn 65 RACCORD M¶LE KKVT 89 Dn 65
1 41062 23 TORNILLO R/CH. D7981 M4.8x16 SCREW R/CH DIN7981 M4, 8X16 SCHRAUBE R/CH DIN7981 M4, 8X16 ECROU R/CH. DIN7981 M4, 8X16
1.1 41164 4 TORNILLO D603 CARROCERO M5x20 SCREW M5x20 VIS CARROSSIER M5x20
1.2 41216 4 TUERCA AUTOBLOC. D985 M5 SELF BLOCKING SCREW D985 M5 SELBSTKLEMMENDE MUTTER D985 M5 ECROU AUTOBLOQUANT D985 M5
1.3 41708 4 ARANDELA D125A M5 WASHER D-125A M5 UNTERLEGSCHEIBE D125A M5 RONDELLE D-125A M5
2 38310 20 MANG. TRANSP. 65x85 mm. 10 BAR. MATERIAL HOSE 65x85 mm. 10 BAR. MATERIALSCHLAUCH 65x85 mm. 10 BAR. TUYAU TRANSP. 65x85 mm. 10 BAR.
4 76300 1 ACOPL. HEMBRA KKMT 89 Dn 65 CUPPLING FEMALE KKMT 89 Dn 65 KUPPLUNG WEIBLICH KKMT 89 Dn 65 RACCORD FEMELLE KKMT 89 Dn 65
5 76303 1 JUNTA ACOPL. 65 mm. 110x14 mm. JOINT CUPPLING 65 mm. 110x14 mm. GUMMIDICHTUNG 65 MM 110X14 mm JOINT RACCORD 65 mm. 110x14 mm.
38381 1 MANG.TRANSP.50 mm (20 MTS) C/ACOPL.
MATERIAL HOSE 50 mm.(20 MTS) WITH
COUPLING
MATERIALSCHLAUCH 50 MM (20 M) MIT
KUPPLUNG
TUYAU TRANSP. 50 mm.(20 MTS)
A/RACCORD
7 7075990000 1 ACOPL. MACHO KKVT 70 P/MANG. 50 CUPPLING MALE KKVT 70 FOR HOSE 50
KUPPLUNG MŽNNLICH KKVT 70 F.
SCHLAUCH 50
RACCORD M¶LE KKVT 70 POUR TUYAU 50
1 41062 28 TORNILLO R/CH. D7981 M4.8x16 SCREW R/CH DIN7981 M4, 8X16 SCHRAUBE R/CH DIN7981 M4, 8X16 ECROU R/CH. DIN7981 M4, 8X16
1.1 41164 4 TORNILLO D603 CARROCERO M5x20 SCREW M5x20 VIS CARROSSIER M5x20
1.2 41216 4 TUERCA AUTOBLOC. D985 M5 SELF BLOCKING SCREW D985 M5 SELBSTKLEMMENDE MUTTER D985 M5 ECROU AUTOBLOQUANT D985 M5
1.3 41708 4 ARANDELA D125A M5 WASHER D-125A M5 UNTERLEGSCHEIBE D125A M5 RONDELLE D-125A M5
8 38320 MANG. TRANSP. 50x70 mm. 10 BAR. MATERIAL HOSE 50x70 mm. 10 BAR. MATERIALSCHLAUCH 50x70 mm. 10 BAR. TUYAU TRANSP. 50x70 mm. 10 BAR
9 707598000 ACOPL. HEMBRA KKMT70 P/MANG. 50 CUPPLING FEMALE KKMT70 FOR HOSE 50
KUPPLUNG MUTTER KKMT70 FÜR
SCHLAUCH 50
RACCORD FEMELLE KKMT70 P/TUYAU 50
20 MANGUERAS
HOSES
SCHLÄUCHE TUYAUX
