Soladora HD 50/07
NOTA: La empresa Utiform se reserva el derecho de efectuar cualquier modificación técnica con tendencia a mejorar la máquina, aunque no esté contemplada en esta manual.
www.utiform.com departamento.técnico@utiform.com
Tfno. +34 96 570 29 82 Fax: +34 96 678 22 99
8
PLACAS DESGASTE CALDERA CONVEY VESSEL WEAR PLATES
VERSCHLEISSBLECHE
CONVEY
PLAQUES USURE CUVE
CONVEY
Nº Ref. Uds Descripción Description Bezeichnung Désignation
A
- 1
PLACA DESG. REDONDA EXTREMOS CALD.
HD 50
ROUND WEAR PLATE VESSEL OUTERS 260 /
HD50
V-BLECH STIRNSEITE KPL.
PLAQUE D'USURE RONDE EXTREME B-260
A/VIS.
1 41204 6 TUERCA D934 M10 SCREW D934 M10 MUTTER D934 M10 ECROU D934 M10
2 4240300083 6 JUNTA GOMA P/PLACAS DESGASTE Ø 8MM RUBBER JOINT FOR WEARPLATES Ø 8MM GUMMIDICHTUNG Ø 8MM
JOINT CAOUTCHOUC P. PLAQUES D'USURE Ø
8MM
3 41716 6 ARANDELA PLANA D9021 M10 ANCHA WASHER FLAT D9021 M10 WIDE UNTERLEGSCHEIBE D9021 M10 RONDELLE PLATE D9021 M10 LARGE
4 41198 6 TORNILLO ALLEN D7991 M10x40 SCREW D7991 M10X40 SCHRAUBE D7991 M10X40 VIS ALENE D7991 M10X40
5 1201060100 1
PLACA DESG. REDONDA EXTREMOS CALD.
HD 50
ROUND WEAR PLATE VESSEL OUTERS 260 /
HD50
V-BLECH HALBSCHALE PLAQUE RONDE EXTREMES CUVE 260 / HD50
6A
80402121 1 CALDERA PARA MÁQUINA STANDARD
VESSEL 260 A1/2 WITH PLATES, COVER,
OUTLET 118
KESSEL MASCHINEN
STANDARDAUSFÜHRUNG
CUVE 260-S/UPPORT-A1/2, AVEC
PLAQUE,COUVERCLE,SORTIE 118
6B
80402120 1
CALDERA PARA MÁQUINA CON TOLVA DE
CARGA
VESSEL 260 A1/2 WITH PLATES, OUTLET 118
KESSEL 260 MIT KESSELDECKEL A 1/2,
VERSCHLEISSBLECHEN,
MATERIALAUSGANG 118MM
CUVE 260-AVEC SUPPORT-A1/2,AVEC
PLAQUE,COUVERCLE,SORTIE 118
B
80606050 2 JUEGO PLACAS DESGASTE SAL. CENTRAL
SET WEAR PLATES CPL. WITH CENTRAL
OUTLET
V-BLECHSATZ KPL.
MATERIALAUSGANG MITTE (4 STÜCK)
JEU PLAQUES D'USURE FOND CUVE SORTIE
CENTR.
7 1201050715 1
PLACA DESG. "CENTRAL" 118 mm "2 PZAS:
B1-B2"
VERSCHLEISSBLECH UNTEN HINTEN PLAQUE D'USURE FOND ARRIERE 2 PCS
8 1201050720 1
PLACA DESG. "CENTRAL" 118 mm "2 PZAS:
C1-C2"
VERSCHLEISSBLECH UNTEN VORNE PLAQUE D'USURE FOND AVANT 2 PCS
9 4240300083 12 JUNTA GOMA P/PLACAS DESGASTE Ø 8MM RUBBER JOINT FOR WEARPLATES Ø 8MM GUMMIDICHTUNG Ø 8MM
JOINT CAOUTCHOUC P. PLAQUES D'USURE Ø
8MM
10 41716 12 ARANDELA PLANA D9021 M10 ANCHA WASHER FLAT D9021 M10 WIDE UNTERLEGSCHEIBE D9021 M10 RONDELLE PLATE D9021 M10 LARGE
11 41204 12 TUERCA D934 M10 SCREW D934 M10 MUTTER D934 M10 ECROU D934 M10
12 41198 12 TORNILLO ALLEN D7991 M10x40 SCREW D7991 M10X40 SCHRAUBE D7991 M10X40 VIS ALENE D7991 M10X40
C
- 2
PLACA DESG. CURVA LISA CALD. HD
50+260 "STR-NEW"
CURVE FLAT PLATE VESSEL V-BLECH LÄNGS OHNE AUSLAUF PLAQUE COURBE LISSE AVEC VIS
13 41198 2 TORNILLO ALLEN D7991 M10x40 SCREW D7991 M10X40 SCHRAUBE D7991 M10X40 VIS ALENE D7991 M10X40
14 4240300083 2 JUNTA GOMA P/PLACAS DESGASTE Ø 8MM RUBBER JOINT FOR WEARPLATES Ø 8MM GUMMIDICHTUNG Ø 8MM
JOINT CAOUTCHOUC P. PLAQUES D'USURE Ø
8MM
15 41716 2 ARANDELA PLANA D9021 M10 ANCHA WASHER FLAT D9021 M10 WIDE UNTERLEGSCHEIBE D9021 M10 RONDELLE PLATE D9021 M10 LARGE
16 41204 2 TUERCA D934 M10 SCREW D934 M10 MUTTER D934 M10 ECROU D934 M10
17 2000015181 1 PLACA CURVA LISA CALD. CURVE FLAT PLATE VESSEL VERSCHLEISSBLECH KURVE PLAQUE COURBE LISSE
