3 Hardware Installation
43
Connecting Audio/Video Cables
NOTE: CONNECT THE AUDIO/VIDEO CABLES TO THE
CORRESPONDINGLY COLORED CONNECTORS.
Composite Video / CVBS (Composite Video Baseband Signal)
with Analog Audio
For a television with a CVBS connector, you can use the option shown in
Figure 7.
Figure 7 Composite Video (CVBS) with Analog Audio
