Page #2 background image
177 mm120 mm
A
B
C
ø12,5 mm
ø13 mm
120 mm59,5 mm
6 mm
6 mm
10 mm
8,5 mm
80 mm
50 mm
CALYPSO 400 500 600
A 819 944 1044
B 762 887 987
C 1162 1387 1644
