V2 CALYPSO Series Instructions

- 65 -
g max
B [mm] C [mm] F [mm]
80° 110 ÷ 130 90 949
85° 110 ÷ 130 100 967
90° 110 ÷ 130 110 986
95° 110 ÷ 130 120 1006
100° 110 ÷ 130 130 1027
110° 110 ÷ 130 140 1057
g max
B [mm] C [mm] F [mm]
80° 130 100 995
85° 130 110 1005
90° 130 120 1015
95° 130 130 1025
100° 130 140 1035
110° 130 150 1045
g max
B [mm] C [mm] F [mm]
100°
200 200 1340
220 220 1320
110°
130 130 1380
140 140 1380
160 160 1380
180 180 1360
CALYPSO 400
CALYPSO 500
CALYPSO 600

V2 CALYPSO Series Specifications

General

Power Supply	24V DC
Connectivity	Ethernet, USB
Display	Touchscreen LCD
Communication Ports	Ethernet, USB
Buttons	User-definable buttons
