V2 CITY11 - Input and Output Terminal Functions

ENGLISH
- 9 -
COURTESY LIGHT
Thisoutputhasanormally-opencleancontactrelaywhichcloses
forapprox.1secondatthestartofanopeningphase.
Thisswitchmaybeusedtoactivateacourtesylighttimer(max.
load:230V-4A).
PLEASE NOTE:Ifthereisnotimer,thecourtesylightcanbe
controlledusingchannel4ofreceiverMR:bistableortimer
programmablechannel(readtheinstructionsforthereceiverMR
thoroughly).
TheswitchisonterminalsK1 and K2.
BLINKER
Thecontrolunitprovidesfortheuseofa230V-40Wor
120V-40Wblinkerwithbuilt-inintermittence.
Connect the cables to terminals K9 and K10.
ELECTRIC LOCK
A12Velectriclockcanbemountedonthegatetoensureagood
closureoftheshutters.
Theelectriclockisactivatedforaxedtimeof1.5seconds.
Thelockadvancetimeisadjustablefrom0.2to0.5seconds
(dip-switch1)
ConnectthecablesoftheelectriclockbetweenterminalsL10 and
L11ofthecontrolunit.
START INPUT
TheSTARTinputispresetforconnectingdeviceswiththeswitch
normally open.
Functiondependsonthemodeofoperationsetbymeansofdip-
switch4.
Step mode
Subsequent Start command cause, in order:
openingg stop g closure g stop
“Inversion” mode
Startduringopeningcausesclosure.
Startduringclosurecausesopening.
Startwiththegateopenalwaysresultsinclosure;the only case
wherethisdoesnotoccurimmediatelyiswhenautomaticclosure
isenabledandstartwhileopeningisnotaccepted:inthisspecic
case,startmakesthepausetimecountstartfromzero,after
whichthegatewillbere-closed.
InbothmodesitispossibletodisabletheStartcommandduring
gateopeningbymeansof
dip-switch3.
Connectthestartinputcontroldevicecablesbetweenterminals
L1 and L6 on the control unit.
PEDESTRIAN START
Withthegateclosed,thepedestrianstartcommandcausespartial
opening(approx.halfway)ofthegateleafconnectedtomotor1.
Subsequentpedestrianstartcommandswillfunctionaccordingto
steplogic.
Duringapedestriancycle,thestartcommandresultsinthe
completeopeningofbothgateleaves.
Connectthepedestrianstartinputcontroldevicecablesbetween
terminals L2 and L6 on the control unit.
STOP
TheSTOPinputisintendedfordeviceswiththeswitchnormally
closed.
TheSTOPcommandcausestheimmediatestopofthegate.
AsubsequentSTARTcommandactivatesthegateintheopposite
directionofmovement.
IftheSTOPcommandisgivenduringopeningorpause,then
therewillbenosubsequentautomaticre-closure.
Connectthestopinputcontroldevicecablesbetweenterminals
L3 and L6 on the control unit.
EXTERNAL ANTENNA
Itisrecommendedtheexternalantennabeusedinorderto
guaranteemaximumradiocapacity.
Connect the antenna hot pole to terminal A1ofthecontrolunit
andthebraidingtoterminalA2
PLUG-IN RECEIVER
Thecontrolunitissuitableforplugging-inanMRseriesreceiver.
m PLEASE NOTE: Pay the utmost attention to the
direction of insertion of plug-in modules.
TheMRreceivermodulehas4channels,eachwithanassociated
commandofthecontrolunit:
• CHANNEL1gSTART
• CHANNEL2gPEDESTRIANSTART
• CHANNEL3gSTOP
• CHANNEL4gCOURTESYLIGHTS
m PLEASE NOTE: Read the instructions supplied with the
MR receiver thoroughly for details on programming the 4
channels and the operational logic
