3.6 - MOTOR OVERRIDING SYSTEM
Intheabsenceofpower,thegatecanbereleased
byoperatingonthemotor:
1. Opentherearhatch
2. Screwanti-clockwise(leftthread)theringnutK
usingthesupplied19”wrenchuntilthepinion
isreleased
Torestarttheautomationproceedasfollows:
1. Screwclockwise(leftthread)theringnutKup
tothelimitgivenbyscrewL
2. Closetherearhatch
3.7 - INSTALLATION LAYOUT
L
K
1 3 E
5
4
A
B
F
D
2
C
LENGTH OF THE CABLE < 10 metres from 10 to 20 metres from 20 to 30 metres
Powersupply230V 3Gx1,5mm
2
3Gx1,5mm
2
3Gx2,5mm
2
Photocells(TX) 2x0,5mm
2
2x0,5mm
2
2x0,5mm
2
Keyswitch 4x0,5mm
2
4x0,5mm
2
4x0,5mm
2
Photocells(RX) 2x0,5mm
2
2x0,5mm
2
2x0,5mm
2
Flashinglight 2x1,5mm
2
2x1,5mm
2
2x1,5mm
2
Antenna(integratedintotheashinglight) RG174 RG174 RG174
A
B
C
D
E
F
1
2
3
4
5
Keyswitch
Pillarphotocells
Pillar-mounteddigitalradioswitch
Safetyedges
WES-ADImodule(viaradiomanagementofedges)
WESsensors
Motor
Transmitter
Receivingmodule
Photocells
Flashinglight
COMPONENTS ADDITIONAL ACCESSORIES
