13 - BLINKER
TheHEAVY1unithastwooutputsforthemanagementofthe
blinker:
1. Z1 andZ2 terminalfora230V-40Wblinkerwithinternal
intermittence
2. H6 (+) andH7 (-) terminalsfora24Vdc-3Wblinker.
Usinga24Vblinkeryouneedtosetthe
SPIA
parameterwith
thevalue
FLASH
(DEFAULT =
W.L.
).
NOTE:Iftheseterminalsareusedforthisfunctionitwillnotbe
possibletoconnectaopengatewarninglight.
Z1Z2Z3Z4Z5
OUTPUT
Z6
H1 H2 H3 H4 H5 H6 H7 H8
230V - 40W24Vdc - 3W
+
-
Thenormaloperationoftheblinkerinvolvesitsactivationduring
bothopeningandclosingofthegate.
Theotheroptionsavailableare:
• Enabledblinkersettopause:youneedtosetthevalue
SI
for
theparameter
LP.PA
• Pre-ashing:theblinkerisactivatedbeforethebeginningof
theopeningandclosingphasesforatimethatcanbesetvia
theparameter
T.PRE
• Pre-ashingduringclosing:theblinkerisactivatedbeforethe
closingphaseforatimeotherthanthatsetforopening.
Thetimecanbesetviatheparameter
T.PCH
14 - OPEN GATE WARNING LIGHT
Theunitisttedwitha24Vdc-3Woutputthatallowsthe
connectionofawarninglight.
Theopengatewarninglightshowsinrealtimethestatusofthe
gate,thetypeofashingindicatesthefourpossibleconditions.
- GATESTOPPED(CLOSED):thelightisoff
- GATEINPAUSEMODE(OPEN):thelightisonandxed
- OPENINGGATE:thelightashesslowly(2Hz)
- CLOSINGGATE:thelightashesfast(4Hz)
Connectthecablesofthewarninglighttoterminals
H6 (+)andH7 (-)
NOTE:iftheseterminalsareusedforthisfunctionitwillnotbe
possibletoconnecta24Vdcblinker
H1 H2 H3 H4 H5 H6 H7 H8
24Vdc - 3W
+
-
SPIA
parametera DEFAULT =
W.L.
(opengatewarninglight)
15 - EXTERNAL ANTENNA
Toguaranteethemaximalradiorangeradioitisadvisabletouse
theexternalantenna.
ConnecttheshieldoftheantennatotheterminalA1 andthehot
poletotheterminalA2.
A1 A2
