16 - CONTROL MODE FROM TERMINAL
BOARD
Tocontrolthegatethroughexternaldevicesyouneedhaveto
connectdeviceswithnormallyopencontactbetweenterminals
S1-S4, S2-S4 orS3-S4 andsetforeachthedesiredfunctionvia
theparameters
ING1
,
ING2
and
ING3
.
Thefunctionsavailableare:
• Start (
START
valuetobeset)
Thisfunctioncorrespondstoagenericactivationcommandand
controlsthefollowingoperations:
- Whenthegateisclosed,anopeningcyclestarts
- Whenthegateisopeningdependsonthesettingofparameter
ST.AP
:
NO
:commandnotactive
CHIU
:thegateclosesimmediately
PAUS
:thegatestops(iftheautomaticclosingmodeisonthe
pausetimecountingstarts)
- Whenthegateisopenandthepausethecountingisnot
active,theclosingstarts
- Whenthegateisopenandthepausetimecountingisactive,
dependsonthemenu
ST.PA
:
NO
:commandnotactive
CHIU
:closingstarts
PAUS
:resetthepausetimecounting
- Whenthegateisclosingdependsonthemenu
ST.CH
:
APRE
:thegatere-opens
STOP
:thegatewillstopandthecycleisconsiderednished
- Whenthegateisstoppedduetoastopcommandorthe
detectionofanobstacle,acommandStartrestartsthegatein
thesamedirectionasitwasbeforebeingstopped.
Iftheparameter
STOP
issetto
INVE
thegateagainmoves,
butintheoppositedirection.
- Whenthegatebeganapartialopeningcyclecommandsa
totalopening
• Partial start (
ST.PE
valuetobeset)
Thisfunctioncorrespondstoapartialopeningcommandand
controlsthefollowingoperations:
- Whenthegateisclosed,apartialopeningcyclestarts;thegate
opensonlyforthepercentageoftravelsetintheparameter
P.APP
- Whenthegatebegananormalopeningcyclethiscommand
hasnoeffect.
- Oncethegatehasstartedapartialopeningcycle,itis
dependentonthemenu
SP.PA
:
PAUS
:thegatestopsandpauses
CHIU
:thegateimmediatelystartsclosing
NO
:thegatecontinuestoopen(thecommandisignored)
• Stop (
STOP
valuetobeset)
Thisfunctioncorrespondstoastopcommand:itistheonly
caseinwhichtheconnecteddevicemustworkwithnormally
closedcontact;itcanbeusedtostopthegateandholditina
lockedposition.
TheoperationoftheSTOPcommanddependsonthevaluesetfor
theparameterSTOP:
-
PROS
:thegatestopsinitscurrentpositionandaslongasthe
contactisopennocommandiseffective.
Oncethecontactisclosedagain,anystartcommandrestarts
thegatethatfollowsitspreviousdirection.
-
INVE
:thegatestopsinitscurrentpositionandaslongasthe
contactisopennocommandiseffective.
Oncethecontactisclosedagain,anystartcommandrestarts
thegateintheoppositedirection.
-
APRE
:thegatestopsanymovementandopenscompletely.If
anactivesafetydevicepreventstheopening,thegatedoesnot
moveuntilthedeviceinvolvedisdeactivated,thenitopens.
SothegateremainslockedintheopenpositionuntiltheSTOP
contactclosesagain.
-
CHIU
:thegatedoesnotstopthemovementimmediately,but
whenitstopsitcloses.
Ifasafetydevicecausesitsre-opening,theoperationiscarried
out,thenagainclosingiscommanded.
Whenthegateisclosed,itremainslockedinthispositionuntil
theSTOPcontactisclosedagain.
• Always opens (
APRE
valuetobeset)
Alwayscontrolstheopening,regardlessofthepositionofthe
gate,ifthegateisalreadyopen,itisineffective.
NOTE:Thiscommandisnotavailablefortheinput
ING3
.
• Always closes (
CHIU
valuetobeset)
Alwayscontroltheclosing:ifthegateisalreadycloseditis
ineffective.
NOTE:ThiscommandisnotavailablefortheinputING3.
• Force dead man mode (
PRES
valuetobeset)
ThiscommandisavailableonlyontheinputING3:whenthe
contactisclosedtheunitisoperatingindeadmanmode.
17 - REMOTE CONTROL MODE
TheHEAVY1unitisttedfortheconnectionofanMRseries
receiver.Thereceiverhas4channels,whichcanbeassociated
withthebuttonsontheremotecontrolandcanhavethe
followingfunctions:
• Channels1and2triggertheopeningcycleaccordingtothe
settingoftheparameter
RX
:
START
:channel1isequivalenttoSTARTcommandand
channel2toPARTIALSTARTcommand
APCH
:channel1isequivalenttothecommandOPENand
channel2tothecommandCLOSE
• Channel3isequivalenttotheSTOPcommand
