In the following pages you can find a functions
diagram with information concerning.
For the use of the function chart proceed as
follow:
• Press DOWN key to flow the chart from the
top to the bottom. The functions dEF, t.AP1,
t.AP2 etc. will be appear.
• Press UP key to flow the chart from the bottom
to the top.
• Press MENU key to flow the chart horizontally;
for example, if the t.ChP function is displayed,
by pressing the MENU key the number 7.0 will
be dispayed.
Increase the number pressing UP or DOWN.
Press MENU to display function t.ChP again.
WARNING LIGHT DESCRIPTION
The warning light shows in real time the state of
the gate:
STOP light off
IN PAUSE light always on
OPENING the light flashes slowly (2 Hz)
CLOSING the light flashes rapidly (4 Hz)
Model PD5 PD5-120V PD7 PD7-120V
Power supply 230VAC - 50Hz 120VAC - 60Hz 230VAC - 50Hz 120VAC - 60Hz
Max motors load 700W 700W 700W 700W
Max accessories load 24V 10W 10W 10W 10W
Working temperature -20 ÷ +60 °C -20 ÷ +60 °C -20 ÷ +60 °C -20 ÷ +60 °C
Protection fuse F1 = 5A F1 = 8A F1 = 5A F1 = 8A
Dimensions 295 x 230 x 100 mm 195 x 145 x 80 mm
Weight 1600 g 1200 g
Protection IP55 IP55
TECHNICAL SPECIFICATIONS
