V2 PD5 User Manual

ENGLISH
43
PD5 - PD7 FUNCTION TABLE
DISPLAY DATA DESCRIPTION
DEF
AULT
DATA
MEMO
DATA
dEF no / Si Load
V2 ELETTRONICA standard data
no
t.AP1 0 ÷ 120 s Gate 1 opening time 22.5
t.AP2 0 ÷ 120 s Gate 2 opening time 22.5
t.APP 0
÷ t.AP1
Opening time of pedestr
ian gate
6.0
t.Ch1 0
÷ 120 s
Gate 1 closing time 23.5
t.Ch2 0
÷ 120 s
Gate 2 closing time 23.5
t.ChP 0
÷ t.Ch1
Closing time of pedestr
ian gate
7.0
t.C2P 0
÷ t.ChP
Closing time gate 2 dur
ing pedestrian cycle
0.0
r.AP 0 ÷ 120 s Gate delay during opening 1.0
r.Ch 0 ÷ 120 s Gate delay during closing 3.0
t.SEr 0 ÷ 120 s Lock time 3.0
t.ASE 0 ÷ t.SEr Lock advance time 0.0
t.inv 0 ÷ 120 s Backlash time 0.0
t.PrE 0 ÷ 120 s Pre-flashing time 1.0
t.rAL 0 ÷ 120 s Slowing down time (PD5 only) 0.0
t.CvE 0 ÷ 120 s Fast closing time after slowing down during closing (PD5 only) 0.0
Pot. 30 ÷ 100% Motor power 40
SPUn no / Si Start off Si
St.AP Start in opening PAUS
no - Start command is not available
ChiU - Command close gate
PAUS - Stop the gate and goes in pause
St.Ch Start in closing StoP
Stop - Start command stop the gate
APEr - Start command open the gate
St.PA Start in pause ChiU
no - Start command is not available
ChiU - Start command closes the gate
SP.AP Pedestrian in opening PAUS
no - Pedestrian start command is not available
ChiU - Pedestrian start command closes the gate
PAUS - Gate goes in pause
Ft.PA Photocell in pause r.PAU
r.PAU - Pause time recharged
t.PCh - Gate stop for a time to be set between 0 to 120 s
Ch.AU Automatic closing no
no - Automatic closing not available
t.PAU - Reclosing is available, the standstill time is set from 0 to 999 s
Luci Courtesy Light (PD5 only)
CiCL - Lights are on trough the whole cycle
t.LUC - Lights start time adjustable from 0 to 999 s 60 s
A
US
- A
uxiliar
y output
tiM - Timed aux out (from 0 to 999 s)
biSt - Aux out relay with bistable functioning
Mon - Aux out relay with monostable functioning
