V2 STARK3-230V User Manual

ENGLISH
- 15 -
FIXING THE GEAR-MOTOR TO THE
BRACKETS
Fixing the gear-motor to the rear brackets. (FIG. 4).
Fixing the gear-motor to the front brackets (FIG. 5).
MANUAL OVERRIDE
Before operating the manual override disconnect the power.
Manual override has been thought for manual opening of the
gate in case of power-cut or motor breakdown.
• Insert the key in the cylinder lock and turn it of 90° clockwise
direction.
• Pull the lever till it is perpendicular to the gear-motor
RESTORE
• Bring back the lever in the original position.
• Inser the key in the cylinder lock and turn it of 90°
anticlockwise direction.
FIG.4 FIG.5
FIG.6
FIG.7
