2.6 Spindle (Drive)
VACo󰀨ersavarietyofspindles/drives(1),suitable
for the most frequently used actuator types.
2.6.1 Spindle Removal
Releasethespindle/drivebypryingwith
two screwdrivers, equally under the edges(2) of
thespindle/drive,usingthehousingasfulcrum.
The spindle has a snap ring that is “released” with
the equal pressure.
2.6.2 Spindle Mounting
Press the spindle down into the spindle shaft hole.
Turntheats(3)intoplaceandpressdown.
Checktoseethatthespindle/driveissetsecurely
in place.
To install the spindle correctly will result in two
“snaps” of the spindle into the housing.
3
1
2
