VAC V200E - Spare Parts List

V200 POSITIONER
www.vacaccessories.com
92026r15
21
Item Description Material Part no Qty
1 ......Housing .................................. Aluminum, painted ........n/a ................... 1
.......- Bearing 15x8 ...............................................................171508 ............ 2
.......-ReliefValveWasher ............. Stainless Steel ..............90126 .............. 1
.......- Rubber Washer .................... Nitrile Rubber ................90035NBR ...... 1
.......- Connection Plate ................. Aluminum, painted ........n/a ................... 1
.......- Connection Plate Gasket .... Nitrile Rubber ................90270NBR ...... 1
.......-ReliefValveSpring ...............Stainless Steel ..............90271 .............. 1
.......-ScrewISO4762M5x25/25 .. Stainless Steel ..............4762052525 .... 3
2 ......Feedback Arm Assembled ............................................91002 .............. 1
.......- Feedback Arm ......................Aluminum, painted ........90006 .............. 1
.......- Ball Bearing .......................... Stainless Steel ..............100404 ............ 1
.......- Screw ISO 7500C M4x12 .... Stainless Steel ..............7500C041212 . 1
.......- Bearing 8x8 .................................................................100808 ............ 2
3 ......Feedback Spring Assembled ........................................91018 .............. 1
.......- Spring Nut mk III ................. Zink ...............................90149 .............. 1
.......- Range Screw mk III .............. Zink ...............................90146 .............. 1
.......- Range Nut L ......................... Zink ...............................90147 .............. 1
.......- Range Nut R ........................ Zink ...............................90148 .............. 1
.......- Top Disc ............................... Zink ...............................90150 .............. 1
.......-KnurledKnobM4at .......... Plastic <PA> .................037040259905 1
.......- Feedback Spring .................. Stainless Steel ..............90018 .............. 1
.......-ScrewISO4017M4x60/60zStainlesssteel ...............4017046060z .. 1
.......- Washer DIN 137B44 ............Steel, Zinkplated ...........137B44 ........... 1
.......- Washer ISO 7089-4 .............Stainless Steel ..............708904 ............ 1
.......- Nut ISO 4032 M6M M4 ........ Stainless Steel ..............93404 .............. 1
.......- Washer ISO 7093-4 .............Stainless Steel ..............709304 ............ 1
.......- Spring Clip mk III .................. Steel ..............................90151 .............. 1
4 ......Membrane Plate with tube .. Aluminum ......................92177 .............. 1
.......- Brass tube ............................ Brass .............................n/a ................... 1
.......- O-ring Ø3x2 NBR70 ............. Nitrile Rubber ................OR3x2NBR ..... 3
.......- O-ring Ø38x2 NBR70 ........... Nitrile Rubber ................OR38x2NBR ... 1
.......- O-ring Ø7x2 NBR70 ............. Nitrile Rubber ................OR7x2NBR ..... 1
5 ......Membrane disc ...................... Aluminum, .....................90133 .............. 1
6 ......Membrane .............................. Nitrile Rubber ................90180NP ......... 1
7 ......Membrane Washer .................Stainless Steel ..............90009 .............. 1
8 ......ScrewISO7047M4x12/12 .... Stainless Steel ..............7047041212 .... 1
9 ......Balance Arm ........................... Stainless Steel ..............91003 .............. 1
10 .....ScrewISO7047M4x08/08 .... Stainless Steel ..............7047040808 .... 2
11 ..... Guide Pin ............................... Stainless Steel ..............90024 .............. 1
12 .....ScrewISO7048M4x16/16 .... Stainless Steel ..............7048041616 .... 2
13 .....Cam* ...................................... Stainless Steel ..............92031 .............. 1
14 .....Cam Nut ................................. Zink ...............................90096 .............. 1
.......-ScrewISO7048M4x8/8 ...... Stainless Steel ..............7048040808 .... 1
15 .....Indicator Screw ...................... Zink ...............................90096 .............. 1
17 .....Indicator Arrow ....................... Plastic<PC/ABS> .........90049A ........... 1
.......Indicator Flag ......................... Plastic<PC/ABS> .........90049F ........... 1
.......- Circlip Indicator Flat ............. Stainless Steel ..............90137 .............. 1
18 .....Front Cover Assembled .................................................91001 .............. 1
.......- Front Cover .......................... Aluminum, painted ........90004 .............. 1
.......-ScrewISO4017M6x40/10z Stainless Steel ..............4017064010z .. 2
.......- Washer ISO 7089-6 .............Stainless Steel ..............708906 ............ 2
.......- O-ring Ø5,1x1,6 NBR70 ....... Nitrile Rubber ................OR5,1x1,6NBR 2
.......-Frontlabel0-90-0(std)* ....... Plastic <PC> .................92018 .............. 1
19 .....O-ring Ø70x1,5 NBR70 .......... Nitrile Rubber ................OR70x1,5NBR 1
20 .....Indicator cover ........................ Plastic <PC> .................90038 .............. 1
21 .....O-ring Ø160x2 NBR70 ........... Nitrile Rubber ................OR160x2NBR . 1
22 .....PilotValveLB(std) ........................................................91020 .............. 1
.......PilotValveSHG(3) .......................................................91009 .............. 1
.......PilotValveSHGHF(4) ..................................................91019 .............. 1
.......-ValveBlock ..........................Aluminium .....................n/a ................... 1
.......-ValveBushing ......................Stainless Steel ..............n/a ................... 3
.......- Spool .................................... Stainless Steel, Gold plated n/a ................. 1
.......- O-ring Ø7,65x1,63 NBR70 ... Nitrile rubber..............OR7,65x1,63NBR 5
.......-ScrewISO4017M5x30/10 .. Stainless Steel ..............4017053010 .... 1
3.2 Spare parts list
Item Description Material Part no Qty
23 .....Cover plate ............................. Aluminum, painted ........90080 .............. 1
24 .....Screw ISO 7048 M5x14 ......... Stainless Steel ..............7048051414 .... 1
25 .....O-ring Ø3x2 NBR70 ............... Nitrile Rubber ................OR3x2NBR ..... 2
26 .....O-ring Ø5x2 NBR70 ............... Nitrile Rubber ................OR5x2NBR ..... 1
28 .....Screw ISO 7048 M5x14 ......... Stainless Steel ..............7048051414 .... 4
30 .....Filter Cover ............................. Stainless Steel ..............90032 .............. 1
.......-ScrewISO7048M4x8/4 ...... Stainless Steel ..............7048040804 .... 1
31......- O-ring Ø3,1x1,6 NBR70 ....... Nitrile Rubber ................OR3,1x1,6NBR 1
32 .....- Main Filter ............................ Plastic <PP>..................90033 .............. 1
33 .....- O-ring Ø17,5x1,5 NBR70 ..... Nitrile Rubber ................OR17,5x1,5NBR 1
37 .....Drive Shaft ............................. Stainless Steel ..............90029 .............. 1
.......- O-ring Ø12x2 NBR70 ........... Nitrile Rubber ................OR12x2NBR ... 1
.......- O-ring Ø15x2 NBR70 ........... Nitrile Rubber ................OR15x2NBR ... 1
38 .....Spindle* .................................. Stainless Steel ..............90092 .............. 1
.......- Circlip spindle ....................... Stainless Steel ..............90093 .............. 1
41 .....Plug1/4” ................................ Brass, Nickel plated ......261014 ............ 1
42 .....BugScreen/Silencer ............ Plated Brass ..................400148 ............ 1
43 .....Plug1/8” ................................ Plastic <PA> ..................90103 .............. 4
45 .....Plug Conduit Holes ................ Plastic <PE HD> ...........90136 .............. 4
48 .....ScrewISO7048M4x8/8 ........ Stainless Steel ..............7048040808 .... 1
49 .....Washer ISO 7089-4 ...............Stainless Steel ..............70894 .............. 1
50 .....Zero Plug ................................ Nitrile Rubber ................90037 .............. 1
52 .....DomeIndicatorB/YKit ..................................................93008 .............. 1
.......-DomeIndicatorB/Y ............. Plastic<PC/ABS> .........92062 .............. 1
.......- Circlip Indicator Flat ............. Stainless Steel ..............90137 .............. 1
.......- Dome Indicator Cover .......... Plastic <PC> .................90044 .............. 1
53 .....IP converter ...................................................................91006 .............. 1
.......-ScrewISO7045M4x35/10 .. Stainless Steel ..............7045043510 .... 2
.......- Pin FRP 6x22 Ni ..................Steel, Nickel plated .......87520622 ........ 2
.......- Washer ISO 7089-4 .............Stainless Steel ..............70894 .............. 2
54 .....V200EtoPConversionPlate .......................................91000 .............. 1
.......- Sealing plate mkII ................ Zink ...............................90156 .............. 1
.......-ScrewISO7045M4x35/10 .. Stainless Steel ..............7045043510 .... 2
55 .....StabilityKit** ..................................................................93027 .............. 1
.......- Stability Plate Upper ............ Aluminum, Anodized .....90039 .............. 1
.......- Stability Plate Lower ............ Aluminum, Anodized .....90040 .............. 1
.......-ScrewISO7048M5x14/14 .. Stainless Steel ..............7048051414 .... 1
.......- Rubber Plug ......................... Nitrile Rubber ................90036 .............. 1
56*** ... Gauge 0-30psi Bottom mount Aluminum ....................400502 ............ 1
57*** ...Gauge 0-30psi Back mount... Aluminum ......................400500 ............ 1
58*** ... Gauge 0-160psi Back mount Aluminum ......................400501 ............ 3
59 .......O-ring Ø5x0.8 NBR70 ............ Nitrile Rubber ................OR5x0,8NBR .. 1
*Camwithotherranges,frontlabelswithotherscalereadingsandspindlessuit-
able for the most frequently used actuator types, are available.
**Certainvalve/actuatorpackagesmayneedadditionaleldstability,whichcan
be accomplished with the stability kit (100% to 300%- depending on orientation
of the kit).
***Gaugesavailableasanoption.Alsoavailableinstainlesssteel.
.......0-30 psi for I port
.......0-160psiforC+,C-andSport
